Production Facilities

A lineup of IJ Printer that can be introduced as production facilities.

Production Facilities

Kenzai JET SP[for Outer Walls and House Materials]

Kenzai JET SP is designed for decorating various types of building board.
Positioning and various corrections by image processing enable practical level positioning.
This is a full-scale production system that pursues stable and continuous printing by reducing the maintenance frequency of the inkjet head as much as possible.
Single-pass Printing: Maximum productivity of 800 m²/h.
Automatic head cleaning and automatic ink supply system.

Items Specification
Head Type Various Heads Compatible with Water-based and UV-curable Inks
*we can also provide the UV lamps necessary for the use of UV-curable inks. If you use water-based inks, please provide your own drying facilities.
Work Size(MAX) 400mm(X-direction)*Any length(Y-direction)
Productivity Approx. 400㎡/h (Standard mode) 800㎡/h (High Speed mode)
Print Resolution 360×360dpi,  360×180dpi
Ink Supply Method Automatic Ink Supply from Main Tank to Sub Tank
Fixing Method of the Substrate Air Vacume Belt
Z-axis Adjustment Approx. 50 mm depending on the thickness of the workpiece:Motorized Adjustment
Image File Form Tiff File Format
Software Windows Software
Dimensions Depends on Specifications
Maintenance Auto Wiping ・Auto Capping System
Safety System Emergency Stop Switch ・ Door Interlock Mechanism

●Please contact us to discuss your customization needs.
