For trial and small lot production
Stage JET [ XY-stage multi-pass printer]
Stage JET is full-dressed, high accuracy industrial inkjet system,
basically installed 6 colors of inks.(CMYK+2colors*)
*LC, LM, W, Clear color etc. *W, Clear coating are available only for UV ink.
Our inkjet system “Stage-JET” is suitable for head/ink evaluation for printing system development.
You could also innovate the system as the actual production equipment.
Customize service is available on request.
Ink types would be your choice from solvent, UV, water-based and oil-based ink.
| Items | Specification |
| Head Type | For Water-base, Oil, Solvent, UV-curable ink |
| Number of Head | 4-Heads base(customize available on request) |
| Head Heater Control | Available depend on head type |
| Print Size | 594mm×841mm(customize available on request) |
| Printing Method | Single and Multi-Pass(1,2,3,4,8,16), unidirectional/bidirectional printing |
| Printing Resolution（X） | Ex.)KM head 360, 720, 1440, 2880 dpi |
| （Y） | Ex.)KM head 360, 720, 1440 dpi |
| Ink Supply System | Main-tank + Sub-tank |
| Fixing Media | Air Vacuum Table |
| Z-axis Adjustment | Manual Adjustment(25mm） |
| Image File Form | Tiff File |
| Software | Windows Application Soft |
| Dimensions | 2020(W)x1720(D)x1563(H)mm (depend on the stage size) |
| Maintenance | Manual or Automatic Wiping/Capping System |
| Option | UV Curing System |
| Safety System | ･Emergency Stop Switch ･ Door Interlock Mechanism |
