Roll JET FP [for Flexible Packaging]
For flexible packaging and various packaging films.
The unique transport system reduces wrinkles and meandering on the film.
Direct printing is possible on flexible packaging film materials such as OPP, PET, Nylon (*).
Uses VOC-less ink that takes safety into consideration for the human body and environment.
Using original printing and drying technology, clear and delicate image expression is possible.
| Items | Specification |
| Compatible Head Type | Piezo Head Compatible with Water-based Ink |
| Number of Heads | Standard One Color 5-Head, Staggered Arrangement |
| Head Heater Control | Ink Heating using Head with a built-in Heater |
| Outside Diameter | 600Φ ｍｍ (max.) |
| Media Width | 560 ｍｍ (max.) |
| Media Weight | 100 kg (max.) |
| Core Inner Diameter | 3 inches. |
| Printing Method | Single-Pass (Roll-to-Roll Printing) |
| Print Resolution | 1200 x 1200 dpi |
| Print Width | 540 mm (max.) |
| Printing Speed | 80 m/min (max.) (*) |
| Ink Supply | Main-Tank + Sub-Tank System |
| Ink Control | Negative Pressure Pump |
| Head Maintenance | Automatic |
| Head Height Adjustment | Electric Motor |
| Image File Form | Tiff File |
| Software | Windows Application Software |
| Drying | Preheat + Main Drying |
| Security System | Emergency Stop Switch + Door Interlock Mechanism |
| Dimentions | W 5160 × D 2730 × H 3070 mm *Not Including PC Racks |
