Roll JET [Roll to Roll Printer]
•High speed roll to roll printing process.
•A single pass print.
•Customize service is available.
•Multiple ink types are available (each ink type is a different model)
– Aqueous Organic Pigment Ink
– Solvent Ink
– UV Ink
•Automatic Maintenance Mechanism for Production Machines
-Ink Color
– Water-based and Solvent-based Ink : CMYK (4-colors)
– UV Ink : CMYKW (5-colors)
| Items | Specification |
| Head Types | For Water-base, Solvent, UV-curable ink |
| Number of Head | Request base |
| Head Heater Control | Depend on InkJet Head Types |
| Roll Width | 300 mm(Media width:250 mm) |
| Core Diameter | 3-inch. (able to change up to 6-inch) |
| Roll Outer Diameter | Max.500 mm |
| Roll Weight | Max.30 Kg |
| Feeding Speed | Max.200 m/min. |
| Printing Method | Single-pass (Roll to Roll) |
| Printing Resolution | Depend on InkJet Head Types. |
| Ink Supplying System | Main-tank & Sub-tank |
| Ink Controlling System | Negative Pressure Regulation |
| Z-axis Adjustment | Manual Adjustment (25 mm） |
| Image File Format | Tiff File |
| Software | Windows Application Software |
| Dimentions | 3570 mm(W) *1370 mm(D）*1705 mm(H) |
| Option | UV Lamp |
| Security System | Emergency Stop Switch ･ Door Interlock Mechanism |
