Wi-For JET[Wide Format IJ Printer]
-
- Roll to Roll, Multi-scanning Wide Format Printer
- Our original suction conveyance system offer you a media flexibility and fine image quality
- Printing to large format media at high speed
- Max. 200sqm/h at high speed mode
- Wi-For JET is ideal printer for use required fine quality and productivity such as soft packaging film, building materials
sheet, paper wall, sign and display and others.
| Items | Specification |
| Print Method | Piezo Print Head |
| Ink | UV-curable or Water-based Ink CYMK４, 6, 8-colors |
| No. of Print Head | 4, or 6, or 8 |
| Print Mode | 1、2、3、4、5、6、8 pass |
| Print Resolution | 300、600、1200dpi |
| Print Speed(1.2m width) | High Speed :Max. 200㎡/h (600x600dpi、2pass,bidirection） |
| Typical：Max.100㎡/h (600x600dpi、4pass、bidirection) | |
| Media Width | ~1,350mm,~1,650mm,~2,150mm *Consultation required for widths over 2.1 m |
| Outside Diameter | Max.Φ400mm *Consultation required for Φ400 mm or more |
| Core Size | 3-inch |
| Media Weight | Max. 250Kg |
| Ink Supply | Automatic Ink Supply from Main Tank to Sub Tank |
| Ink Control | Negative Pressure Control |
| Head Maintenance | Automatic Head Wiping |
| Head Capping | Capping by Manual Operation |
| UV | LED-UV, Metal Halide/Mercur Lamp |
| Print Data | 1 or 2bit TIFF File separated to CMYK colors |
| Software | Windows Application |
| Options | ・RIP ・Dryer for Water-based Ink |
